Specifications

MYSPHERE 3 has been developed by LB-acoustics Messgeräte GmbH applying their core competences in sound and vibration measurement technology.
Meeting the requirements of the audiophile community all measurements are carried out according to the latest technical standards. This includes simple sound measurement as well as mechanical vibrations and psychoacoustic tests. But the final examination is made by the human ears of our test persons, which significantly influences the whole design concept.

general technical data

  • Style
    hovering next to the ears, fully open
  • Sensitivity
    96 dB / 1 mW RMS = 115 dB SPL/V eff. (at Ear-Drum Reference Point)
  • Maximum input power
    60 mW
  • Rated Impedance
    15 Ohms or 110 Ohms
  • Transducer type
    dynamic
  • Transducer size
    40 x 40 mm
  • Diaphragm
    squared, glass-foam enforced
  • Membrane excursion
    4 mm
  • Frequency response
    20 Hz – 40 kHz (-10 dB)
  • Magnetic structure
    radial, fully vented
  • Magnet type
    Neodymium N52
  • Magnet density
    1.5 T
  • Weight
    345 g (without cables)

Frequency response with ear compensation

Burst decay

Step response

Impulse response

Frquency response in near field

Impedance and phase (above 3.1, below 3.2)
